Yellow Transmission Line Stringing Tools , 16 Mm 200 M Fiberglass Duct Rodder

Yellow Transmission Line Stringing Tools , 16 Mm 200 M Fiberglass Duct Rodder
Yellow Transmission Line Stringing Tools , 16 Mm 200 M Fiberglass Duct Rodder Yellow Transmission Line Stringing Tools , 16 Mm 200 M Fiberglass Duct Rodder Yellow Transmission Line Stringing Tools , 16 Mm 200 M Fiberglass Duct Rodder

Large Image :  Yellow Transmission Line Stringing Tools , 16 Mm 200 M Fiberglass Duct Rodder

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO CE
Model Number: LS001
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiable
Packaging Details: Std export term
Delivery Time: 7days after payment
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200 sets / week
Detailed Product Description
Prodcut Name: Duct Rod Length: 200 M
Wheel Diameter(mm): 300 Mm Wheel Material: Rubber
Made In: NINGBO CHINA Technology: Pultrusion
High Light:

electrical wire pulling tools

,

conductor pulling tools

Yellow Color Transmission Line Stringing Tools , 16mm 200m Fiberglass Duct Rodder



Fiberglass Duct Rodder Description

FRP Conduit Snake Rod is applied in tow lead-rope through a pipe,it is auxiliary means. Surface smooth and high resilience,so the FRP perforator with ease passes the narrow channel.

Pull Push Rod Specially Points

1) Vey high Density polyethylene (Grade: for the insulating and jacketing of Telecommunication Cables) is used in the outer diameter coating.

2) Duct Rodders will equipped with different size reel according to the length of rod.

3) Best tensile strength and bending properties, which make it to go through narrow pipes easily.

4) Good temperature adaptability, the product will not soften in hot weather / nor become brittle in cold weather.
There are meter marks on the protect layer of duct rodder, which can be used for measuring distance. Marks are printed by professional printing machine, which has the advantage of strong adhesion, clear writing, waterproof, anti-ultraviolet, it can be still clear even after using many times.

Duct Push Rodder Data Sheet

Specification Rod Diameter (mm) Φ4,Φ4.5,Φ5,Φ6,Φ8,Φ10,Φ11,Φ12,Φ13,Φ14,Φ15,Φ16,
Rod Length (m) 30~500
Frame Spec.(mm) 1300x450x1330,1200x420x1220,980x350x1000,680x240x700, etc
Wheel Diameter(mm) 300mm
Wall thickness of Metal Frame 2.2mm
Color blue, yellow, red, white etc
Material Rod Inner Extruded by fiber glass and high strength resin at high temperature
Rod Outer High Density polyethylene coating
Iron Frame Steel with high-temperature sprayed plastic or Spray coating
Wheel rubber
Brake Yes
Drawing head copper
Physical Character Density 150g/m
Working temperature -40°C to +80°C
Breaking tension 4.5T
Bending Radius 295mm
Technology Pultrusion
Packing Inside plastic woven strip wind around the frame
Outside Wooden pallet and Wooden box

Note: we offer various sizes and colors for any specific requirement as customers' demand.

Traceable Duct Rod Spare Parts
