Manually Operated Hand Winch Puller LSJ 10KN Hand Turned Winch Lightweight

Manually Operated Hand Winch Puller LSJ 10KN Hand Turned Winch Lightweight
Manually Operated Hand Winch Puller LSJ 10KN Hand Turned Winch Lightweight Manually Operated Hand Winch Puller LSJ 10KN Hand Turned Winch Lightweight

Large Image :  Manually Operated Hand Winch Puller LSJ 10KN Hand Turned Winch Lightweight

Product Details:
Place of Origin: NINGBO CHINA
Brand Name: Linkai
Certification: ISO
Model Number: LJS
Payment & Shipping Terms:
Minimum Order Quantity: 2sets
Price: Get the latest
Packaging Details: Wooden case
Delivery Time: 3-5 wrok days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100sets/day
Detailed Product Description
Model: LJS Rated Load: 10kn
Name: Hand Turned Winch Handspike Hole Dia: 35mm
Weight: 25kg Feature: Light Weight
High Light:

gasoline powered winch

,

portable capstan winch

Manually Operated Winch Model LSJ 10KN Hand Turned Winch with Handspike Hold 35mm







This hand turned winch is usually fixed on the ground. The winch handspike is pushed manually.

Main Specifications

Item Number Model Rated Load (kN) Weight (kg) Drum bottom of groove diameter(mm Handspike hole diameter (mm)
09201 LJS-10 10 25 120 25
09202 LJS-30 30 65 160 65
09203 LJS-50 50 75 160 75



This manul turned winch is used when it fixed on the ground, pushing winch handspike manually. Users should provide the handspike themselves.

It has the light weight, and very easy operation features.
